LS-RM-DS500 500 kN Servo Rock Direct Shear System
LS-RM-DS500 500 kN Servo Rock Direct Shear System is a rock direct shear testing machine for joints and interfaces for ISRM Suggested Methods workflows.
Balanced 500/500 kN Capacity
Independent normal and shear loading covers a wide range of intact rock, discontinuity, and interface test programs.
Controlled Shear Rate
The 0.03–4 mm/min horizontal rate range supports staged loading and displacement-controlled shear workflows.
Six-Channel Data Acquisition
Load and displacement channels are displayed, stored, zeroed, and calibrated through the integrated computer workflow.
Application & Search Guide
Rock joint, weak-plane, and interface direct shear testing
LS-RM-DS500 500 kN Servo Rock Direct Shear System is a rock direct shear testing system for intact rock, joints, bedding planes, weak layers, fault materials, and rock-concrete interfaces under ISRM Suggested Methods. It supports slope, tunnel, dam, mining, and foundation laboratories that need controlled normal loading with synchronized shear force and displacement measurement.
What is LS-RM-DS500 500 kN Servo Rock Direct Shear System used for?
LS-RM-DS500 500 kN Servo Rock Direct Shear System is used for rock joint and interface direct shear testing workflows in civil engineering materials laboratories, quality control labs, research programs, and construction material acceptance testing.
Which standards does LS-RM-DS500 support?
LS-RM-DS500 supports ISRM Suggested Methods. Lithostek can also configure reporting fields, accessories, and calibration documents around local project or laboratory requirements.
Can Lithostek configure LS-RM-DS500 for my laboratory?
Yes. Lithostek application engineers can review specimen format, target standards, throughput, power supply, data output, and training requirements before quoting a suitable configuration.
